About DSCope
DSCope is a series of USB-based oscilloscope, up to 100MHz bandwidth, max 1GSa/s sample rate, 2M real-time and 256M single record length.
DSCope is small(115mmx74mmx16mm), and can be packed in a shirt pocket. Combined with big screen and powerful performance computer, DSCope series oscilloscope can provide you amazing signal capture and analyzer experience.
How to choose an OSCILLOSCOPE?
We have prepared A CHECKLIST for you
Model |
Bandwidth |
Max Sample Rate |
Record Length |
Channels |
DSCope U2P20
|
50MHz
|
200MSa/s
|
2M Real-time / 32M Single
|
2
|
DSCope U2B100
|
100MHz
|
1GSa/s
|
20K Real-time / 32K Single
|
2
|
DSCope U3P100
|
100MHz
|
1GSa/s
|
2M Real-time / 256M Single
|
2
|
1. Stability and Safety
72 hours burn-in test
5 years,1800 days and nights,300 improvements
Patented Ground Protection technology
Ground Protection: If you accidentally connect the ground terminal of probe to certain power supply *, the ground connection will be automatically disconnected to protect your oscilloscope and computer from damage.
* For specific protection range, please refer to the specifications of different products
2. Capture Rate and Delay
DSCope has a FPGA-based Waveform Processing Engine, similar to the desktop oscilloscope, instead of an MCU-based software implementation
High Capture Rate and Smooth Waveform
High Waveform Real-time Refresh Rate
DSView software can efficiently process waveforms and
display dynamic waveforms at a stable frame rate
DSCope U3P100 support USB3.0 interface
Bandwidth up to 5Gbps,10 times of USB 2.0
Achieve microsecond level transmission delay
3. Bandwidth and Sample Rate
Analog front-end bandwidth up to 100MHz
Single-chip high-speed ADC instead of low-end splicing scheme
Real-time sample rate up to 1GSa/s, not equivalent sample rate
