☆ INTRODUCTION
This connection board DESPI-C02 is aim to help users to learen how to use the E-paper Display easier, and it is used for Good Display's black-white E-paper Display and three-color (black, white and red-Yellow):1.54'', 2.13'', 2.6'', 2.66'', 2.7'', 2.9'', 3.71'', 4.2'', 5.83'', 7.5'' and 11.6''.
This is an adapter board of raspberry pi development platform, at the same time it also has interface for frontlight and touch screen.
What is raspberry pi?
The Raspberry Pi is an ARM-based microcomputer motherboard. It uses an SD / MicroSD card as a memory hard disk. There are 1/2/4 USBports and a 10/100 Ethernet interface around the card motherboard (A type has no network port) It can be connected to a keyboard, mouse and network cable, and has a TV output interface for video analog signals and an HDMI high-definition video output interface. The above components are all integrated on a motherboard that is only slightly larger than a credit card, and can be replaced by all the basic functions of the PC. The TV and keyboard can perform many functions such as spreadsheets, word processing, playing games, playing high-definition video, and so on.
☆ MAIN PARAMETERS
|
PART NUMBER
|
DESPI-C03
|
|
PLATFORM
|
STM32, Arduino, Raspberry Pi and so on
|
|
FUNCION
|
Connection E-paper Display with DESPI-M02
|
|
OUTSIDE DIMENSION
|
52x36mm
|
|
INTERFACE
|
USB Interface
|
|
POWER INPUT
|
DC3.3V
|
|
FEATURE
|
Fully and Partial refresh
|
|
OPERATING TEMP.
|
-20~70℃
|
☆ DRIVE BOARD
● DESPI-V3.0 (STM32 Platform/Universal)
● DEArduino-03 (Arduino Platform)
● ESP8266-03 (WiFi)
● ESP32-03 (WiFi / Bluetooth)
☆ SPECIFICATION DOWNLOAD
1) DESPI-C03 Specification
2) DESPI-C03-SCH
