Overview

1. The module integrates high-precision gyroscopes, accelerometers, and geomagnetic field sensors, and uses high-performance microprocessors and advanced dynamics calculation and Kalman dynamic filtering algorithms to quickly solve the current real-time motion posture of the module.

2. The module integrates an attitude solver and cooperates with the dynamic Kalman filter algorithm to effectively reduce measurement noise and improve measurement accuracy. It can accurately output the current attitude of the module in a dynamic environment, with an attitude measurement accuracy of 0.2°, extremely high stability, and even better performance than some professional inclinometers.

3. The Z-axis heading angle is added to the geomagnetic sensor filter fusion, which solves the cumulative error caused by the drift of the gyroscope integral in the 6-axis algorithm, and can output heading angle data stably for a long time.

4. The output content can be selected arbitrarily, the data output frequency is 200Hz, and the default is 10HZ.

5. Reserve 4 expansion ports, which can be configured as analog input, digital input, digital output and other functions.

6. Using stamp hole gold plating technology, it can be embedded in the user's PCB board. The 4-layer PCB board technology is thinner, smaller and more reliable.

7. Bluetooth 5.0: supports Android/IOS operating system (actual use depends on the final device)

Accelerometer parameters

Gyroscope parameters

Magnetometer parameters

Pitch and roll angle parameters

Heading angle parameter

Module parameters
