Three core advantages define excellent sound quality
1. Bluetooth 5.3 offers lossless transmission.
►Equipped with a Bluetooth 5.3 module, it boasts faster and more stable connections with strong anti-interference capabilities. Supporting high-quality audio transmission, it frees you from the constraints of cables, allowing you to easily play music from your phone or tablet and enjoy nearly lossless wireless sound quality.
2. Pure low-frequency sound with deep bass.
►Key technology: The low-frequency channel employs a Linkwitz-Riley filter circuit. It precisely segments frequency bands and effectively filters out mid- and high-frequency clutter, ensuring the purity of low-frequency signals. As a result, the bass sounds tight, full, elastic, and never sloppy.
3. Full power, quiet startup and shutdown
►Equipped with 2 TPA3116D2 chips, it boasts dual independent processing cores, delivering powerful performance! The output power is genuine and not falsely labeled: the bass channel reaches 100W, and each stereo channel delivers 50W.
►Excellent circuit design ensures "no impact sound during power-on/off", making the moment of power-on and power-off very quiet, protecting your speaker and enhancing the user experience.
Ingredients:
Precision sealed 09 type potentiometer: long wear-resistant lifespan, effectively prevents dust and oxidation, smooth adjustment without noise.
Lossless inductance for audio: It significantly reduces hysteresis loss and core saturation, resulting in richer sound details and stronger dynamics.
Independent treble and bass adjustment for the main channel: With an adjustment range of ±12dB, you can fine-tune according to your listening preference, easily satisfying whether you prefer powerful bass or clear treble.
Weight: 94.6g
PCB size: 95*112mm
Power supply voltage: DC12V-24V (connected to 5525)
Input method: 3.5MM stereo jack + high-definition Bluetooth 5.3
Output power: Subwoofer 100W + stereo 50W*2, 4 ohms
Subwoofer 60W + Stereo 30W*2 8 ohms
Output terminal: 3.96 pitch output terminal
Frequency response: 10Hz-20kHz; Signal-to-noise ratio: 90dB
Operational amplifier: N5532*4
