What's easyPIC-40?
The easyPIC-40 Development Board is a flexible and convenient development, demonstration and testing platform for Microchip's 8-bit PIC16F/PIC16LF and PIC18F/PIC18LF microcontrollers (MCUs) with 40 DIP packaging. It features lots of simple and basic modules to begin developing and learning a complete embedded application. All the modules on board are fully independent, which makes it easy and free to connect. The easyPIC-40 is an old friend. It has been with us for three generations. Many of us made our first steps in embedded world with easyPIC-40. Today it has thousands of users: students, hobbyists, enthusiasts and professionals. It is used in many schools and other educational institutions across the globe. We have sold them over 3000pcs in the world in the passed 3 years. It provides an low-cost easy-to-use platform with common modules to bring you into the colorful embedded world. Of course, we are not perfect and we asking ourselves what we can do to make such a board even better, and at the same time, we are looking forward to receiving your valuable suggestions.
What's on Board
Power Supply
For connection with a power supply source,the easyPIC-40 uses a Jack EX-PWR. The power supply voltage level can vary from +7-10V DC.The easyPIC-40 also can be powered using a USB canble.
Programmer/Debugger Requirement
An external PIC programmer or Debugger is required to download code to the DIP-40 PICs on the board.It supports many Programmers or Debuggers like PICKIT2，PICKIT3 or ICD2 etc.
Microcontrollers Supported
easyPIC-40 supports most PIC microcontrollers of DIP Package with 40pin.The followings shows the Frequently-used microcontrollers:
| PIC16CR64 |
PIC16CR65 |
PIC16C64 |
PIC16C64A |
PIC16C65 |
PIC16C65A |
PIC16C65B |
PIC16C67 |
PIC16C74 |
PIC16C74A |
| PIC16C74B |
PIC16C77 |
PIC18C442 |
PIC18C452 |
PIC16C661 |
PIC16C662 |
PIC16C765 |
PIC16C774 |
PIC16(L)F1517 |
PIC16(L)F1519 |
| PIC16(L)F1567 |
PIC16(L)F1717 |
PIC16(L)F1719 |
PIC16(L)F1777 |
PIC16(L)F1779 |
PIC16(L)F1784 |
PIC16(L)F1787 |
PIC16(L)F1789 |
PIC16(L)F1904 |
PIC16(L)F1907 |
| PIC16(L)F1934 |
PIC16(L)F1937 |
PIC16(L)F1939 |
PIC16(L)F15375 |
PIC16(L)F15376 |
PIC16(L)F18875 |
PIC16(L)F18876 |
PIC16(L)F18877 |
PIC16(L)F19175 |
PIC16(L)F19176 |
| PIC16F74 |
PIC16F77 |
PIC16F871 |
PIC16F874A |
PIC16F874 |
PIC16F877 |
PIC16F877A |
PIC16F884 |
PIC16F887 |
PIC16F914 |
| PIC16F917 |
PIC16(L)F707 |
PIC16(L)F724 |
PIC16(L)F727 |
PIC16F747 |
PIC16F777 |
|
|
|
|
| PIC18F45J10 |
PIC18F44J10 |
PIC18(L)F43K20 |
PIC18(L)F44K20 |
PIC18(L)F45K20 |
PIC18(L)F46K20 |
PIC18(L)F43K22 |
PIC18(L)F44K22 |
PIC18(L)F45K22 |
PIC18(L)F46K22 |
| PIC18(L)F45K40 |
PIC18(L)F46K40 |
PIC18(L)F47K40 |
PIC18(L)F46K42 |
PIC18(L)F45K42 |
PIC18(L)F47K42 |
PIC18(L)F45K50 |
PIC18(L)F45K80 |
PIC18(L)F46K80 |
PIC18F45Q10 |
| PIC18F46Q10 |
PIC18F47Q10 |
PIC18F452 |
PIC18F442 |
PIC18F448 |
PIC18F458 |
PIC18F4410 |
PIC18F4220 |
PIC18F4221 |
PIC18F4320 |
| PIC18F4321 |
PIC18F4331 |
PIC18F4420 |
PIC18F4423 |
PIC18F4431 |
PIC18F4439 |
PIC18F4450 |
PIC18F4455 |
PIC18F4458 |
PIC18F4480 |
| PIC18F4510 |
PIC18F4515 |
PIC18F4520 |
PIC18F4523 |
PIC18F4525 |
PIC18F4539 |
PIC18F4550 |
PIC18F4553 |
PIC18F4580 |
PIC18F4585 |
| PIC18F4610 |
PIC18F4620 |
PIC18F4685 |
PIC18F4680 |
PIC18F4682 |
PIC18F4685 |
|
|
|
|
Note
1: Some supported microcontroller models may be omitted, and the actual situation shall prevail.
2. In addition to supporting 5V PIC microcontrollers, easyPIC-40 also supports 3.3V PIC microcontrollers with an "L". Therefore, all PIC microcontrollers with an "L" that are not listed in this table but have a compatible pin layout are supported. |
Packing List
easyPIC-40(Comes with the microcontroller as the title says),---------------------------1pcs;
Dupont 1P-1P(F) DIY Cable,---------------------------------------------------------------------------8pcs;
Dupont 8P-8P(F) DIY Cable,--------------------------------------------------------------------------- 3pcs;
Downloads
