Luckfox PicoKVM remote control server remote installation HDMI operation and maintenance artifact HID control with network port

Name: Luckfox PicoKVM remote control server remote installation HDMI operation and maintenance artifact HID control with network port
Brand: MicroHello
SKU: PicoKVM-001
Price: 44 USD
Availability: InStock

SKU: PicoKVM-001

0.0 (0)

1 Sold

$44.00 ~~$79.00~~

Luckfox PicoKVM remote control server remote installation HDMI operation and maintenance artifact HID control with network port

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

Description

Product Overview

Item	Specification
Main Chipset	RV1106G3
Memory	256MB
eMMC	8GB
Video Input Resolution	Up to 1920x1080 @ 60 fps
Video Encoding	H.264 Hardware Encoding
Video Latency	80 ~ 200 ms
Audio Transmission	√
USB Keyboard/Mouse Emulation	√
USB Storage Emulation	√
UEFI/BIOS Access Range	√
Wake-on-LAN	√
Power Control	GPIO Control
LCD Display	Resolution 240 x 240, Touch Supported
Storage Expansion	Micro SD Card
Power Input	Powered via Host USB 5V
Network Connection	10M/100M Ethernet
IO Expansion Header	SH1.0 10Pin
Power Consumption	Approx. 1.6 W

IO Expansion Header Pin Definition

The following link is for PicoKVM Introduction，Getting Started，Remote Access，Remote OS Installation，PicoKVM Firmware Update etc.
https://wiki.luckfox.com/Luckfox-PicoKVM
